Application:
Alumina ceramic foam filter can effectively remove and absorb large or small impurities in molten aluminum,improve the surface quality, product performance and microstructure effectiveness. Mainly used in the domestic, construction, electricity, condensing tubes, cable and other aluminum alloy precision casting.ceramic foam filter can effectively remove and absorb large or small impurities in molten aluminum,improve the surface quality, product performance and microstructure effectiveness. Mainly used in the domestic, construction, electricity, condensing tubes, cable and other aluminum alloy precision casting.
Properties:
Pore Density (PPi): 10-60
Porosity (%): 80-90
Operating temperature(ºC) : ≤1100
Bending Strength (MPa): ≥0.6
Compression Strength (MPa):≥ 0.8
Thermal Shock Resistance(times/1100ºC): 6
Filter aperture selection rules
1. Aluminum alloy bar choose: 10-30ppi
2. Long-term casting choose: 30-50ppi
3. High quality aluminum profile or plate choose :40 or 50ppi
4. Double zero wave continuous casting and rolling choose: >50ppi
5. Other specifications can be customized as your requirments
Size and Capacity
| Size (mm) | Weight (Kg) | Flow Rate (Kg/s) | Weight (Kg) | Flow Rate (Kg/s) |
| 10ppi | 20ppi | |||
| 50×50×22 | 42 | 2 | 30 | 1.5 |
| 75×75×22 | 96 | 5 | 67 | 4 |
| 100×100×22 | 170 | 9 | 120 | 7 |
| Dia50×22 | 33 | 1.5 | 24 | 1.5 |
| Dia75×22 | 75 | 4 | 53 | 3 |
| Dia90×22 | 107 | 5 | 77 | 4.5 |
| Large size (Inch) | Weight (Ton) 20,30,40ppi | Flow Rate (kg/min) | ||
| 7"×7"×2" | 4.2 | 25 ~ 50 | ||
| 9"×9"×2" | 6 | 25 ~ 75 | ||
| 10"×10"×2" | 6.9 | 45 ~ 100 | ||
| 12"×12"×2" | 13.5 | 90 ~ 170 | ||
| 15"×15"×2" | 23.2 | 130 ~ 280 | ||
| 17"×17"×2" | 34.5 | 180 ~ 370 | ||
| 20"×20"×2" | 43.7 | 270 ~ 520 | ||
| 23"×23"×2" | 57.3 | 360 ~ 700 | ||
Detailed Images
Shipping
Lead time: 10-15days after signed the contract
Packing
- Inside packing: Filters are put in small box and Layered packaging. There is cardboard between each layer.
- Outside packing: Cartons&Pallets. Three layer corrugated cartons and export special pallets .
- The mark on cartons can be designed according to the customer's request.
